How a One-Byte Discriminator Can Silently Break Anchor's Event System

Introduction

Anchor is the most widely used framework for building Solana programs. At the heart of every Anchor program is a dispatch() function — auto-generated code that routes incoming transaction data to the correct instruction handler based on a discriminator prefix.

By default, Anchor uses an 8-byte discriminator derived from sha256("global:<instruction_name>")[..8]. Since all default discriminators share the same length, the starts_with() matching used in dispatch is unambiguous and safe.

However, since version 0.31.0, Anchor supports custom discriminators via the #[instruction(discriminator = [...])] attribute. This feature introduced a subtle gap: the framework performs no validation on custom discriminator values — no minimum length, no prefix-collision check, and no comparison against internal sentinel bytes. This creates a developer footgun where a carelessly chosen discriminator can silently disable critical framework functionality.

Background: How Anchor Dispatch Works

Every Anchor program compiles down to a dispatch() function that checks each global instruction's discriminator using starts_with(). The key observation: global instructions are checked first, and the Event CPI sentinel is checked last. When all discriminators are 8 bytes, this ordering is fine — no 8-byte sequence can be a prefix of another 8-byte sequence.

fn dispatch(program_id: &Pubkey, accounts: &[AccountInfo], data: &[u8]) -> Result<()> {
    // 1. Check each global instruction's discriminator
    if data.starts_with(instruction::Foo::DISCRIMINATOR) {
        return __private::__global::foo(program_id, accounts, &data[8..])
    }
    if data.starts_with(instruction::Bar::DISCRIMINATOR) {
        return __private::__global::bar(program_id, accounts, &data[8..])
    }

    // 2. Check the Event CPI sentinel (checked AFTER all global instructions)
    if data.starts_with(anchor_lang::event::EVENT_IX_TAG_LE) {
        return __event_dispatch(program_id, accounts, &data[8..])
    }

    // 3. Fallback
    Err(ErrorCode::InstructionFallbackNotFound.into())
}

But what happens when a custom discriminator is shorter than 8 bytes?

The Discovery

The Overrides parser in lang/syn/src/lib.rs:83–104 accepts any arbitrary byte sequence as a custom discriminator with no validation whatsoever:

"discriminator" => {
    let value = match &arg.value {
        Expr::Lit(lit) if matches!(lit.lit, Lit::Int(_)) => quote! { &[#lit] },
        Expr::Array(arr) => quote! { &#arr },
        expr => expr.to_token_stream(),
    };
    attr.discriminator.replace(value)  // No validation whatsoever
}

There is no check for: (1) Minimum length — even an empty [] discriminator is accepted, (2) Cross-instruction prefix collisions — a 1-byte discriminator can shadow an 8-byte one, (3) System sentinel collisions — a discriminator can collide with EVENT_IX_TAG_LE.

Meanwhile, the existing collision check in idl/src/build.rs:372–390 only compares within the same category — accounts vs accounts, events vs events, instructions vs instructions. It never compares instruction discriminators against the system-level EVENT_IX_TAG_LE constant ([0xe4, 0x45, 0xa5, 0x2e, 0x51, 0xcb, 0x9a, 0x1d]).

Root Cause Analysis

1. Dispatch ordering (dispatch.rs:19–85)

The generated dispatch() checks global instruction discriminators first, and the EVENT_IX_TAG_LE sentinel last. When a custom instruction has discriminator [0xe4] — the first byte of EVENT_IX_TAG_LE — the starts_with(&[0xe4]) check matches before starts_with(&[0xe4, 0x45, ...]) ever gets a chance:

// event_hijacker checked first
if data.starts_with(instruction::EventHijacker::DISCRIMINATOR) {  // &[0xe4]
    return event_hijacker(...)
}
// ... other instructions ...

// EVENT_IX_TAG_LE checked later — DEAD CODE
if data.starts_with(anchor_lang::event::EVENT_IX_TAG_LE) {  // &[0xe4, 0x45, ...]
    return Err(EventInstructionStub.into());
}

2. Missing cross-category check (idl/src/build.rs)

The existing collision check (added in PR #3157) does not compare instruction discriminators against internal sentinel values like EVENT_IX_TAG_LE.

3. No constraint on custom discriminators (lang/syn/src/lib.rs)

The Overrides parser accepts any byte sequence without validation. Combined with (1) and (2), there is nothing preventing a developer from accidentally choosing discriminator bytes that shadow system functionality.

Proof of Concept

Minimal program

use anchor_lang::prelude::*;

declare_id!("HYFvCMUDQNu2iniPh7wpDYAscUkEs7aTorebutFsYB7Q");

#[program]
pub mod discriminator_shadowing {
    use super::*;

    // discriminator [0xe4] = first byte of EVENT_IX_TAG_LE
    // Shadows the event CPI dispatch handler
    #[instruction(discriminator = [0xe4])]
    pub fn event_hijacker(ctx: Context<BasicCtx>) -> Result<()> {
        let log = &mut ctx.accounts.log;
        log.last_handler = "event_hijacker".to_string();
        Ok(())
    }

    pub fn initialize(ctx: Context<InitCtx>) -> Result<()> {
        ctx.accounts.log.last_handler = String::new();
        Ok(())
    }
}

Key test

it("sending EVENT_IX_TAG_LE data dispatches to event_hijacker", async () => {
  const eventTag = Buffer.from([0xe4, 0x45, 0xa5, 0x2e, 0x51, 0xcb, 0x9a, 0x1d]);

  const ix = new anchor.web3.TransactionInstruction({
    keys: [
      { pubkey: provider.wallet.publicKey, isSigner: true, isWritable: false },
      { pubkey: logPda, isSigner: false, isWritable: true },
    ],
    programId: program.programId,
    data: eventTag,
  });

  const tx = new anchor.web3.Transaction().add(ix);
  await provider.sendAndConfirm(tx);

  const handler = await getLastHandler();
  assert.strictEqual(handler, "event_hijacker");
  // ^^^ PROVES: Event CPI tag was intercepted by event_hijacker
});

Impact Assessment

This issue is not an externally exploitable security vulnerability. Custom discriminators are set at compile time by the program author — an external attacker cannot modify them. The Anchor development team has confirmed this assessment.

However, it is a meaningful developer footgun worth hardening against:

Suggested Hardening

• Minimum length check: Reject discriminators shorter than a minimum (e.g., 8 bytes) in Overrides::parse, or at least emit a compile-time warning for short discriminators.
• Prefix-collision check at IDL build time: Extend the existing check_discriminator_collision! to detect when one instruction's discriminator is a prefix of another's.
• System sentinel collision check: Compare custom discriminators against known internal sentinels (EVENT_IX_TAG_LE) and reject or warn on prefix collisions.

Timeline

• Discovery: Identified during review of custom discriminator handling introduced in PR #3137
• PoC: Built and verified on Anchor 0.32.1
• Disclosure: Reported via GitHub issue #4272
• Developer response: Acknowledged as worth hardening, not classified as a security issue
